Loot

All · 12 min read

A chest's offer: Take All or Take None.

When an enemy dies it leaves a treasure chest where it fell. The chest's tier (Wooden, Silver or Gold) is decided at death, so you can see it on the ground; its contents are decided only when you open it, from the enemy's drop table. Opening shows a panel that asks you to take everything or nothing. Chests stay in the world until opened, across area changes and save and load. Separately, collectable orbs sit in the level and give their item when you walk into them. The idea that makes the rest make sense: a chest holds a drop table and a tier, never a list of items.

What you can change

• What an enemy drops, and how often each chest tier appears: Build a drop table.
• How rare an item is, and its colour: Set and style item rarity.
• A chest placed by hand, an orb to walk into: drag BP_XenoCore_TreasureChest or B_XenoCore_CollectableOrb into the level and fill in the settings in Settings.
• How the chest looks and opens: the chest Blueprint's Presentation settings, or a child Blueprint using its three events (see Extending it).

How it fits together

Piece	Class / sample asset	Job
Drop table (data asset)	Inventory/Loot/DA_XenoCore_Drops_Grunt, _Skirmisher, _Bulwark, _Brute (one per minion family), DA_XenoCore_Drops_Minion (base minion and dummy)	Tier odds, and a pool of weighted items per tier
Enemy loot settings	Enemy Blueprint · Drop Table, Chest Class, Always Gold Chest, Chest Drop Delay	Which table, which chest, forced gold, reveal delay
Chest	Inventory/Loot/BP_XenoCore_TreasureChest	Holds tier and table, rolls on open, offers the contents
Open ability	Inventory/Loot/GA_XenoCore_OpenChest	Granted near a chest by Lyra's interaction system
Chest label	Inventory/Loot/W_XenoCore_ChestLabel	Floating label near a closed chest
Popup	UserInterface/HUD/W_XenoCore_LootPopup	Lists the items; Take All or Take None. Shown automatically when a chest opens
Collectable orb	Inventory/Collectables/B_XenoCore_CollectableOrb	Walk-in pickup that respawns
Icons	UserInterface/Foundation/DA_XenoCore_ItemIcons	Category glyphs on each popup row

Drop table settings

Setting	What it does
Gold Chance	Chance of a gold chest, checked first. Default 0.02
Silver Chance	Chance of silver if gold did not land. Default 0.25. Otherwise wooden
Pools	One entry per tier (Wooden, Silver, Gold)
Pool › Min Items, Max Items	How many items a chest of that tier rolls. Default 1–2
Pool › Entries › Item Def, Weight	Candidate items. Weights are relative, not percentages; 0 parks an entry without removing it
Pool › Entries › Min Level, Max Level	A level band: the entry only drops from an enemy inside it. The level is the dying enemy's, stored on the chest. 0 means no bound
Pool › No Duplicate Equipment	A piece of equipment comes out of one chest at most once. Materials still repeat. If the pool runs out of drawable entries, the chest holds fewer items rather than repeating one
Pool › Guarantee One Of Rarity	Empty by default. When set, a chest from this pool always holds at least one item that rare. If the roll found none, its last pick is redrawn from the qualifying entries. Xenoblade 1's silver and gold chests always hold one rare material

Each item in a chest is rolled independently, so the same material can appear twice (equipment too, unless No Duplicate Equipment is on).

The sample tables give each minion family its own common and rare material, a silver chance between 18% and 34%, and level-banded armour in the gold pool: the Legendary Vanguard Plate only drops from a level 10+ enemy. Gems are never in a chest; they come from quests and shops. To see what a table really pays out, run XenoCore.Loot.Simulate <table> [level] [chests] in the console.

Each Item Def is a soft reference. Holding a drop table (every enemy and chest does) loads none of its items; only the items actually rolled load, when the chest is opened.

Chest tier and item rarity are separate. The tier is the chest, and its odds come from the drop table. Rarity belongs to each item; see Set and style item rarity.

They meet in three places:

• Each rarity's Lowest Chest Tier (Common → Wooden, Rare → Silver, Legendary → Gold). A drop table warns, but does not error, when an item sits in a lower pool than that.
• The chest beam, coloured by the rarity its tier stands for, so a gold chest glows Legendary purple. Turn this off with the chest's Use Rarity Beam Colour.
• The loot panel, which lists the rarest items first.

Lifecycle

At death. If the enemy has a Drop Table, it rolls the tier (gold if Always Gold Chest is ticked), spawns its Chest Class on the floor where it died, turned to face the player, and tells the chest its table, tier and the enemy's level. The chest hides itself for Chest Drop Delay (2 s) so it does not appear in the middle of the death animation, and cannot be opened until then. No Drop Table means no chest.

Squads. An enemy that belongs to an enemy spawner squad follows Xenoblade Chronicles' squad rule (the spawner's Squad Loot Rule, on by default):

• Only the last member killed drops a chest. The others drop nothing, and their loot is not added to it: a squad is worth one chest, not one per member.
• The chest is gold at three times the usual chance (the spawner's Squad Gold Multiplier, 3), and otherwise silver, never wooden. A table with no silver pool falls back to wooden.
• Its contents come from the squad leader's drop table and level, whichever member died last. The leader is the first enemy of the spawner's first Members entry, so put the type whose loot the squad should give first.

Waiting. An unopened chest stays in the world. It has no timer and nothing despawns it, and it survives leaving the map and saving and loading. The save subsystem keeps a record for every map the party has visited:

Chest	What is remembered	How it comes back
Dropped by an enemy, unopened	Chest class, position, drop table, tier, source level	Respawned when the map begins play. It still rolls its contents on open, so a reload gives a new roll
Placed in the level	Only what has happened to it: emptied, or opened with items left in it	The level brings the actor back; on its own BeginPlay it asks the save for its record, then removes itself or restores its leftovers
Opened, holding items the bag had no room for	The leftover items themselves, not a table	Offers exactly those items again, never a re-roll

Leaving a map sweeps its dropped chests into the record; a save writes every map's records; a load replaces them; a new game clears them. Placed chests report their own changes as they happen, so a World Partition cell that streams out and back in is still correct.

Opening. Walk up to a chest and the interact prompt offers its verb. Pressing it opens the chest: the lid plays, the chest rolls its contents now from the table and tier, and after the lid the XenoCore.Loot.Message.ChestOpened message announces the offered items (see Events). Nothing has entered the bag yet.

Choosing. W_XenoCore_LootPopup appears, focused on Take All:

• Take All adds each item to the party bag, one at a time, and every menu updates. Anything over an item's Max Carried stays in the chest: the panel shows those rows in Rejected Colour with "(no room)" after them, and the hint line reads "No room for the items in red. They will stay in the chest." The chest stays open-able until it is empty, and offers exactly the leftovers next time.
• Take None discards everything the chest offered, leftovers included, and the chest is finished.

Back (B or Escape) does nothing on this panel: you must answer it. While it is up, the interact button belongs to the panel and the character cannot jump.

After. A chest that has nothing left to offer fades and removes itself after Despawn Delay.

Collectable orbs. Walking within Collect Radius of an orb adds its Item To Grant to the bag, broadcasts XenoCore.Collectable.Message.Collected, and hides the orb. If Respawns is on, it comes back after Respawn Seconds (300).

Settings

Setting	Where it lives	What it does
Drop table settings	Drop table asset	See the table above
Drop Table, Chest Class, Chest Spawn Height	Enemy Blueprint › XenoCore › Loot	Loot source, chest Blueprint, clearance above the floor
Always Gold Chest	Enemy Blueprint › XenoCore › Loot	Force gold. Can be set per placement
Chest Drop Delay	Enemy Blueprint › XenoCore › Enemy › Loot	Reveal delay. Can be set per placement
Drop Table, Tier, Source Level	A chest placed in a level › XenoCore › Loot	For hand-placed chests. Source Level is the level the table's bands roll against
Lid Open Angle, Lid Open Time, Flip Hinge Side, Front Yaw Offset, Lid Open On Spawn	Chest Blueprint › XenoCore › Loot › Presentation	The lid
Beam Height, Beam Width, Beam Intensity, Beam Opacity, Beam Fade Time	Chest Blueprint › XenoCore › Loot › Presentation	The tier-coloured light beam
Despawn Delay, Offer Delay After Lid	Chest Blueprint › XenoCore › Loot › Presentation	Timing after the answer and before the popup
Label Height, Label Range	Chest Blueprint › XenoCore › Loot	The floating label
On Tier Set, On Opened, On Resolved	Chest Blueprint events	Your own tier colours, sounds and effects
Row Colour, Row Font Size, Rejected Colour	Popup widget › XenoCore › Loot	Popup look; Rejected Colour marks the "(no room)" rows
Item To Grant, Collect Radius, Respawns, Respawn Seconds, Orb Effect, Collect Sound	Placed orb › XenoCore › Collectable	The orb

Fails silently: a chest tier with no pool opens empty

Every tier a chest can roll needs its own pool with entries. A missing pool gives an empty chest rather than falling back to another tier. Only a warning in the Output Log says so. The sample minion can roll all three tiers, so its table needs all three.

Fails silently: renaming a placed chest resets it

A hand-placed chest's save record is keyed by the actor's name in the level. Rename it, delete and re-place it, or duplicate the level, and existing saves no longer match it: a chest the player emptied comes back full, and nothing is logged. Settle placed chests' names before you ship, and do not rename them in an update.

Fails silently: the chest must answer the interaction trace channel

A custom chest whose collision does not respond to Lyra_TraceChannel_Interaction is never found: no prompt and no way to open it, with nothing logged. Build chests from BP_XenoCore_TreasureChest.

Fails silently: the chest's open ability must be the exact Blueprint

The chest's interaction option names GA_XenoCore_OpenChest. Lyra finds that ability by exact class, so pointing it at a parent class makes the option disappear.

Fails silently: an orb on an interaction collision profile

An orb's volume must overlap pawns only. On an Interactable_* profile, the chest's interact prompt starts offering the orb.

Extending it

• Your own drop table: duplicate DA_XenoCore_Drops_Minion into your own folder (Content/MyGame/Loot), fill all three pools, and set it on your enemy. See Drop table.
• A hand-placed chest: drag BP_XenoCore_TreasureChest into a level and set its Drop Table, Tier and Source Level.
• A different chest look: right-click BP_XenoCore_TreasureChest, choose Create Child Blueprint Class, and use its three events (On Tier Set, On Opened, On Resolved). Do not build a chest from a plain Actor: only the shipped chest can be opened with the interact button.
• Not built yet: taking specific items from a chest (only Take All and Take None exist). Outside a spawner squad, every enemy with a table drops its own chest.
• Do not build a pickup on Lyra's own pickup system: it puts items in the bag behind XenoCore's back, so carry limits are skipped.

For programmers: classes

Drop table UXenoCoreDropTable; chest AXenoCoreTreasureChest (C++ because Lyra's IInteractableTarget cannot be implemented in Blueprint); popup UXenoCoreLootPopupBase, shown by UXenoCoreLootPopupSubsystem on XenoCore.Loot.Message.ChestOpened; orb AXenoCoreCollectableOrb. The chest answers Lyra_TraceChannel_Interaction and grants GA_XenoCore_OpenChest; the popup blocks jumping with Status.XenoCore.Looting. Do not implement Lyra's IPickupable: it adds to the bag directly (only the bag watcher announces it, and carry caps are skipped) and passes a stack count, which the one-entry-per-item bag does not use.

Why it's built this way

For programmers

• Roll on open. Deciding contents at open rather than at death is the genre's behaviour, and it means a chest only needs a table pointer and a tier.
• Chests persist, so no "encounter ended" signal is needed to decide when to hand out loot.
• The drop table is a data asset, not a component: it is static, shared by every enemy of a type, and read once, at death.
• The chest is C++ because Lyra's IInteractableTarget cannot be implemented in Blueprint. It is shaped on ShooterCore's ALyraWorldCollectable.
• The popup cannot be backed out of because closing it without an answer would leave a rolled, opened chest with no way back in. It consumes the back action rather than ignoring it, so back reaches nothing underneath either.
• Everything enters the bag through the inventory statics, so menus, badges and quests update.
